Feature
The most cutting edge technology in duplication, our Intelligent 9 series USB duplicator is professional, standalone and efficient. It can duplicate a full range of USB drives starting from 4 and up to 59 targets. Speed and flexibility are key factors in satisfying customer needs. Simplicity, a PC or other software are not required; the USB drive duplicator provides a reliable, worry-free copy environment for users, without the risk of virus corruption. This USB duplicator series is integrated with a high-speed compare function to ensure data copies with 100% accuracy. It also boasts quick format capabilities. These features greatly increase efficiency and production productivity.
The Intelligent 9 USB duplicator is not only competent, but also has several ingenious smart device check functions; flash devices quality check, real capacity, device speed and formatting.
The Intelligent 9 USB duplicator is an economical solution for data copy and disposal via USB flash drives. It contains smart, reliable and beneficial functions that provide an outstanding performance with quality that will save you time and money.
Impeccable High Speed
Intelligent Copy Option
Systems and Files (Quick Copy Mode)
Whole Media
Support High Compatibilities with Various USB Devices
Due to unique redundant power design, it can support special medias with sufficient power supplies, such as: USB 2.0/3.0 external USB hard drives, MP3 players, etc.
Quality Testing / Checking Functions
H3 Read Only Test
Determines if the flash is readable. This test will not modify pre-existing data.
Capacity Check
Verifies initial sector and the final sector the connected flash device within 2 seconds.
H5 Write/Read Test
Overwrites machine-generated values to all sectors in the NAND flash, and verifies them to determine quality. Once the test passes, then devices are formatted into FAT.
Read/Write Speed Check
This function performs a read/write benchmark of the connected devices within 8 seconds.
H6 Quality Test
Resembling the H5 test, it overwrites machine generated-values only to the empty sectors without disturbing pre-existing data, partitions, and formats.
Flash Speed and Capacity Filtration
Real-Time Monitoring
Monitor real-time status via PC through USB cable link.
Easy Maintenance
With a specially redesigned and improved structure, users can easily change the sockets in 3 simple steps, which takes roughly 1 minute.
STEP 1
Unscrew and remove the cover of the socket.
STEP 2
Replace a damaged socket with a new one.
STEP 3
Screw the cover.
User-Friendly Design
Modular Sockets
Interfaced sockets are subjected to wear-and-tear caused by frequent connections and disconnects. Modular sockets enable quick replacements while reducing downtime, effectively making this solution a long-term and cost-effective ownership.
Ergonomic & Compact Proportions
The refined ergonomic proportion reduces the flash duplicator by 50% to 70% compared to traditional chassis design.
Model |
UB905S |
UB910S |
UB920S |
UB930S |
UB940S |
UB960S |
UB9120S |
||||||
Targets |
1-4 |
1-9 |
1-19 |
1-29 |
1-39 |
1-49 |
1-119 |
||||||
Speed |
2GB/min. (33MB/sec.) *Actual performance is dependent on media transfer speeds. |
Specifications |
Capacity |
*Embedded controller is designed to support capacities over 18TB+. *Constant improvement supports latest market-available devices. |
Operating Type |
Supports PC link for monitoring |
|
Stand alone operation |
||
Language Support |
English, Japanese |
|
Display |
Monochrome LCD Display |
|
Status LED |
LED(Red/Green) on each slot |
|
Control Button |
4 push buttons(▲, ▼, OK, ESC) |
|
Features |
Copy Function |
Quick Copy (Systems & Files Copy)/Whole Media |
Compare Function |
Bit by Bit data comparison |
|
Diagnostic Function |
Speed Test; Capacity Test; A2 Fake Card Test |
|
H3 Test: Read only testing |
||
H5 Test: Read & Write testing |
||
H6 Test: Read & Write testing without data area |
||
Erase Function |
Quick Erase; Full Erase; DoD Erase |
|
Format Function |
FAT16/32 Format |
|
Compatibilities |
Flash Devices Compatible |
USB 2.0/ USB 1.1/ USB Flash/ USB 3.0/ USB HDD |
Format Supported |
Quick Copy: FAT16/32/64, NTFS, Linux(Ext2/Ext3/Ext4), MAC(HFS, HFSX, HFS+) |
|
Whole Media Copy: All Formats |
||
File system supported |
All (Windows, Linux, Other stand-alone systems) |
|
Hardware Specifications |
Power Supply |
12V Adapter |
Working Temperature |
5°C ~ 45°C |
|
Storage Temperature |
-20°C ~85°C |
|
Working Humidity |
20% ~ 80% |
|
Storage Humidity |
5% ~ 95% |
|
Dimension(cm) |
From 24.1x19.5x11.5 to 45x30x29.5 |
|
Weight(kg) |
From 1.9 to 19 |
|
Certification |
FCC, CE, RoHS |
